Descrizione

Tipo Amplificatore: Classe-D (Digitale Design: 4 Cannali + Subwoofer Thermal Control: Thermal Management Contro Power Supply: MOSFET Power Supply Design: DC-DC PWM Power Supply Board Circuitry: S.T.A.R. Circuitry Current Protection: Over-Current, Over-Voltage and Thermal Protection Power Indicator: Top Mounted Blue LED Power Indicator 4-Channel Speaker Level Input Crossover: Variable Lowpass & Highpass Filter Built-in Bass EQ Built-in Subsonic Filter Final Outputs: Direct FET Board Design: 6-layer Glass Epoxy PC Board Continuously Adjustable Gain Control Remote Bass Control ( RUX-KNOB sold separately ) Max Power Output Ratings Max Power: 1200W RMS Power Ratings Per Channel into 40hms, 14.4V (<1%THD+N): 4 x 50W +200W Per Channel into 2ohms, 14.4V (s1%THD+N): 4 x 75W+ 300W Bridged into 40hms, 14.4V (<1%THD+N): 2 x 150W Sound Tuning Crossover Frequencv (LPF): 50 - 400Hz (-12dB/oct.) for Subwoofer Crossover Frequencv (HPF): 50 - 40047 (12dR/oc+ ) for cy 1/2/3/4 EQ (Equalizer): Bass EQ (fc=50Hz) 0 to +12dB Subsonic: OFF / 5 - 30Hz (-24dB/oct, Dimensioni Heat Sink: 210 x 58 x 230 mm Footprint: 270 x 58 x 230 mm Power Requirements: 14.4V DC (11 - 16V) Input Sensitivity (RCA Input): 0.2 - 4.0V Input Sensitivity (Speaker Level Input): 0.5 - 10\ Impedenza Ingresso: >10k ohms Frequency Response (+0, -3dB: 1W into 4 ohms) for CH- 1/2/3/4: 5Hz -45kHz Frequency Response (+0, -3dB: 1W into 4 ohms) for Subwoofer: 5-400Hz Frequency Response (+0, -1dB: 1W into 4 ohms) for CH- 1/2/3/4: 7Hz -30kHz Frequency Response (+0, -1dB: 1W into 4 ohms) for Subwoofer: 10Hz - 300Hz THD+N (10W into 4 ohms) for CH-1/2/3/4: 0.02% THD+N (10W into 4 ohms) for Subwoofer: 0.008% THD+N (Rated Power into 4 ohms) for CH- 1/2/3/4: 0.07% THD+N (Rated Power into 4 ohms) for Subwoofer: 0.04% Damping Factor for CH-1/2/3/4: > 500 Damping Factor for Subwoofer: > 1000 Signal to Noise (Rated Power into 4 ohms) for CH-1/2/3/4 103dB Signal to Noise (Rated Power into 4 ohms) for Subwoofer: 107dB
