Prodotto usato qualche volta. Vendo per inutilizzo.
Caratteristiche principali
90 watt per canale su 6 Ohm / 72 watt in 8ohms
Alta specifica stadio phono integrato
Alimentatori avanzati per la fase pilota
Ibrido del disegno Brio-R e Elicit-R
Dedicato mini telecomando incluso
Pre-amp out / Record Out / 4 ingressi di linea
Nuovo trasformatore personalizzato
Specifications
Power Supply
Voltage: 230v & 115v
Frequency: 60/60Hz
Power Consumption: 250 Watts
230v Fuse: T3.15AL 20mm
115v Fuse: T5AL 20mm
Dimensions W 430mm x D 320mm x H 80mm
Output power
72.5W 8Ω both channels driven - Design centre rating
90W 6Ω both channels driven - Rega speaker
impedance rating
113W 4Ω both channels driven
Phono input
Sensitivity (72.5W 8Ω1.7mV (Load 47K in parallel with
220pF)
Maximum input level: 100mV
Line input
Sensitivity (72.5W 8Ω 164mv (Load 30-50K)
Maximum input level: 10v
Tape output
Level: 164mV with rated input
Output impedance: 470
Line output
Level: 625mV with rated input
Output impedance: 600
