Amplificatore Rotel RA 840 BX3 100W

Descrizione

vendo per cambio progetto. Numero di transistor A semiconduttori. Semiconduttori Principio generale Amplificatore audio Gamme d'onda - senza Particolarità Hi-Fi equipment Tensioni di funzionamento Alimentazione a corrente alternata (CA) / 120 or 220 or 240Volt Altoparlante - Per cuffie o amplificatori esterni Potenza d'uscita 100W (indistorta) Materiali Mobile di metallo Radiomuseum.org Modello:Stereo Integrated Amplifier RA-840BX3- Roland Electronics Co. Ltd., Forma Apparecchio per ripiani a scaffale (come i componibili HiFi). Dimensioni (LxAxP) 430x66x319mm / 16.9x2.6x12.6inch Annotazioni A 2 x 50 watt Hi-Fi stereo integrated amplifier. Press buttons for Power and Speaker Remote. Rotary controls for Bass, Treble and Volume/Balance. Rotary switches for Tone (On, Off, Mono), Tape Monitor, and Function (Phono, CD, Tuner, AV/Aux1, AV/Aux2). Jack for Headphones. Push button on the back for MM or MC selection. Continuous Power Output : 50 watts per channel, min. RMS both channels driven into 8Ω from 20Hz to 20kHz with no more than 0.3% Total Harmonic Distortion Speaker load impedance : 4 - 16Ω Headphones load impedance : 4 - 16Ω Input Sensitivity/Impedance : Phono (MM)....... 2.5mV/47kΩ Phono (MC)........ 250µV/180Ω CD.................... 150mV/20kΩ Tuner ............... 150mV/20kΩ Tape 1, 2........... 150mV/20kΩ AV/Aux 1 ,2....... 150mV/20kΩ Versions/Power Requirements 120 V AC 60Hz 220 V AC 50Hz 240 V AC 50Hz 120/220/240 V AC 50-60Hz Switchable Peso netto 7.7kg / 16 lb 15.4 oz (16.96 lb) Letteratura / Schemi (1) - - Manufacturers Literature (Owner's Manual for the RA-840BX3) Letteratura / Schemi (2) - - Manufacturers Literature (Technical Manual for the RA-840BX3)
