Descrizione
Specifiche meccaniche
TelaioFull Carbon frame Toray T700, 29”, Integrated battery, Tapered, Internal routing, Rear travel 160 mm, 12x148 mm E-Thru, UDH hanger
ForcellaRockShox DOMAIN Gold R eMTB, Debon Air, 29", Rebound adjustment, Travel 160 mm, 1.5 Tapered, 15x110 mm
AmmortizzatoreRockShox Deluxe, Debon Air, 230x65
Serie sterzoAcros for Ursa, 1.5”, Internal routing
GuarnituraFSA CK320, 34T MegaTooth
CambioShimano XT RD-M8100 SGS Shadow Plus, 12s
ComandiShimano Deore SL-M6100 Rapidfire-Plus, 12s
FreniMagura MT5, Four piston, Rotor RT30 203 mm / 203 mm
Pacco pignoniShimano CS-M6100, 12s, 10/51
PedaliAlu MTB Full+
MozziF: "Shimano TC500B, 15x110, CL, 32h // Glory Wheel, 15x110, CL, 32h" R: "Shimano TC500B, 12x148, CL, MicroSpline, 32h // Formula, 12x148, CL, MicroSpline, 32h"
CerchiRadiale X30, eDesign | Asymmetric, Tubeless Ready, 622x30c
Attacco manubrioAlu, Barbore 35 mm, Extension 35 mm
Piega manubrioAlu, 780 mm, Barbore 35 mm, Rise 15 mm
ReggisellaDropper A1, Diameter 31.6 mm, remote
SellaSelle Royal SRX
Coperture"F: Schwalbe Magic Mary Evo, Addix Soft, Super Trail, TLE, 29”x2.60” R: Schwalbe Big Betty EVO, Addix Soft, Super Trail, 29”x2.60
Peso24,6 kg
Specifiche elettriche
Coppia massima85 Nm
Tipo sensoreTorque
Batteria800 Wh
Tipo caricabatteria4 A
Tempo di ricaricaUp to 6,9 hours
Velocità max assistita25 km/h
DisplayBosch Purion200
Potenza"Eco: 60 % Tour+: 60-340 % EMTB: 140-340 % Turbo: 340 %"
