ATC SCM-19A Diffusori attivi Hi-End

Descrizione

Diffusori in condizioni eccellenti, completi di tutti gli accessori e imballi originali. Overview of ATC SCM19A:: New ATC designed and built dual suspension 25mm soft dome HF unit with precision alloy wave guide. “SL” spec bass driver with 75mm integral Soft Dome. 9kg optimised short-coil/long gap motor assembly. On-board grounded source 182 watt Class A/B Bi-amplifier. Active filters and overload protection Specifiche di ATC SCM19A: Drivers: HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm SL Matched Response: +/- 0.5dB Frequency Response (-6dB): 54Hz-22kHz Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical Max SPL: 108dB Crossover Frequency: 2.5kHz Connectors: Male XLR Input sensitivity: 1V Filters: 2nd Order critically damped with phase compensation Overload Protection: Active FET momentary gain reduction Fault Protection: DC fault protection and thermal trip. Fault indication on rear panel mounted LED Amplifier Output: 150W LF, 32W HF Cabinet Dimensions (HxWxD): 980x370x344mm (spikes add 25mm to height, grill adds 34mm to depth) Weight: 31kg Prezzo trattabile
