Descrizione
Vendo Sansui SD-5000 Reel To Reel Tape Deck Recorder 4 Track 2 Channel. Perfettamente funzionante , esteticamnete in ottime condizioni.
Posso Spedire
Informazoni tecniche
Type Stereo tape deck
Track system 4-track 2-channel recording and playback
Reel dimensions Maximum 7
Tape speed and deviation 19cm/s, 9.5cm/s, ± 0.5%
Heads Erase : 4 tracks, 2 channels
Recording : 4 tracks, 2 channels
Playback : 4 tracks, 2 channels
Reverse playback : 4 tracks, 2 channels
Motor For Capstan : 4 Pole / 8 Pole, 2 Speed Hysteresis Synchronous Motor
For Reel : 2 x 6-pole induction motors
Early winding time Approximately 90 seconds (1,200 ft tape)
Wow and flutter 0.08% or Less (19cm/s)
0.12% or Less (9.5cm/s)
Frequency characteristic 19cm/s : 15 Hz to 25 kHz (20 Hz to 20 kHz ± 3 dB)
9.5cm/s : 15 Hz to 15 kHz (30 Hz to 12 kHz ± 3 dB)
SN ratio (relative to total distortion factor) 60 dB or more
Crosstalk 60 dB or more (track to track, 1 kHz)
Channel separation 50 dB or More (1 kHz)
Reproduction preamp distortion factor 0.15% or Less (1 kHz, Output 1.2 V)
Tape Recording and Playback Distortion Factor 1.2% or less (1 kHz, 0 VU = 0.3 V)
3% or less (1 kHz, + 6 VU)
Erasing effect 60 dB or more
Input Sensitivity / Impedance Mic : 0.5mV/50k Ω
Line : 70mV/100k Ω
DIN : 14mV/100k Ω
Output level High : 1.2 v maximum (0 VU = 0.775 v)
Low, DIN : 0.35 V maximum (0 VU = 0.225 V)
Bias frequency 100kHz
Mixing circuit Line1 and Line2, Line1 and MIC
Recording mode Stand-By, Stereo, Mono-L, R
Monitor Playback, Source
Power supply voltage 100 VAC, 50Hz/60Hz
Power consumption 95W
External dimensions Width 420x Height 486x Depth 253 mm
Weight 20.2kg
